OVERVIEW
Get real-time cold storage environment data to keep your products safe!
The InTemp Cold Storage Monitoring System is an automatic system that monitors the temperature and relative humidity (CX450) of your cold storage and sends alerts if it goes out of range. The logger/s also feature a built-in LCD display to view temperature and relative humidity readings, visual alarms plus the ability to view and change the minimum and maximum temperature on the data logger without interrupting the logged data.
InTempConnect cloud software also provides data reports so you can see how your cold storage is performing over time. With this valuable information, you can optimize your storage space to ensure products are stored at the right temperature. That way, you can make critical product-disposition decisions quickly and avoid any costly product loss.
You’ll have peace of mind knowing that your products are being stored at the correct temperature, thanks to our accurate data reporting and alerts.
Contact us today to learn more about InTemp’s cold storage monitoring system!
✓ Automation:
Use the CX5000 Gateway for data download reports and immediate text/email notifications of critical excursions
✓ Compliance:
Comprehensive 21 CFR Part 11 compliant solution with NIST calibrated loggers and a 1-year calibration certificate, and secure data storage and transmission
✓ Reporting:
Use data tags to easily identify problematic storage units, and to organize/group logger data for advanced customized reporting
✓ Increase Visibility:
Monitor multiple units worldwide to ensure product safety and efficacy, reduce costs, and increase efficiencies
-
DATA LOGGERS (CX403 | CX450)
InTemp CX403 & CX450 Data Loggers
InTemp CX403 Ambient Temperature Bluetooth Data Logger
The InTemp ® CX403 data logger features an internal sensor for monitoring ambient temperature. The logger communicates wirelessly via Bluetooth Low Energy to mobile devices. The CX403 features a built-in LCD display to view ambient temperature, advanced audible and visual alarm capabilities for notification of temperature excursions, and a NIST Certification of Calibration.
Features
- Integrates with mobile and cloud platforms for a 21 CFR Part 11 compliant solution
- Easy-to-read display with current and daily min/max temperatures
- Bluetooth transmission of data and alarm states
- Logger setup and download of data in seconds – without a PC or cable
- Real-time alerts and automatic data downloads with optional CX Gateway device
- +/- 0.5C accuracy for reliable temperature readings
- Battery-powered to guard against local power loss
InTemp CX450 Temp/Relative Humidity Data Logger
The InTemp CX450 Temp/RH data logger monitors temperature and relative humidity in storage and transportation environments. The logger uses Bluetooth Low Energy (BLE) technology to wirelessly communicate with the InTemp CX5000 Gateway and/or the free InTemp mobile app and send data to the free InTempConnect cloud platform. The external sensor provides highly accurately temperature (-30C to 70C) and humidity (0% to 95%) readings.
The CX450 Temp/RH logger also features a built-in LCD display to view temperature and relative humidity readings, visual alarms (and unique audible alarms), and battery level – plus the ability to view and display minimum and maximum readings, without affecting logged data.
Features
- Includes two-point NIST Certificate of Calibration, per USP guidelines, which is good for one year
- Integrates with mobile and cloud platforms for a 21 CFR Part 11 compliant solution
- Easy logger setup and data download in seconds
- LCD display, with ability to clear min/max temp and RH readings
- Unique audible alarms for temp, RH, and combined temp/RH
- AAA battery-powered to guard against local power loss
- + 0.5C accuracy for reliable temperature readings from -30C to 70C
- + 3% accuracy for reliable RH readings from 0% to 90% (+ 3.5% accuracy for reliable RH readings greater than 90% at 25C)
- Free InTemp mobile app to configure logger, view data, and access the free InTempConnect cloud software service
- Real-time alerts and automatic data downloads with optional CX5000 Gateway device
Comparison
CX403
CX450
Who is this for? Required to follow GDP & GMP requirements specifically - Internal sensor only (No probe)
- GDP/GMP compliant
- Refrigerated to ambient monitoring
Required to follow GDP & GMP requirements specifically - Internal temp and humidity sensor only (No probe)
- GDP/GMP compliant
- Refrigerated to ambient monitoring
- Humidity monitoring
What does it monitor? Ambient Room Temperature Ambient Temperature and Relative Humidity NIST Calibration One point NIST calibration – Internal ambient sensor only Two point NIST calibration – Internal ambient sensor only, temp & humidity (2 points each) NIST Expiration 1 year NIST certificate – As recommended by GDP/GMP 1 year NIST certificate – As recommended by GDP/GMP NIST Points Internal Sensor: 25.0°C (77.0°F) Int. Sensor Point 1: 0°C (32.0°F) Int. Sensor Point 2: 40.0°C (104.0°F)
Humidity Point 1: 35.0% @ 25.0°C
Humidity Point 2: 75.0% @ 25.0°C
Temperature Sensor
Range -30° to 70°C (-22° to 158°F) -30° to 70°C (-22° to 158°F) Accuracy ±0.5°C from -15° to 70°C (±0.9°F from 5° to 158°F)
±1.0°C from -30° to -15°C (±1.8°F from -22° to 5°F)±0.5°C from -30° to 70°C (±0.9°F from -22° to 158°F) Resolution 0.024°C at 25°C (0.04°F at 77°F) 0.024°C at 25°C (0.04°F at 77°F) RH Sensor
Range N/A 0 to 95% (non-condensing) Accuracy N/A ±3% from 0% to 90% and ±3.5% from greater than 90% typical at 25°C (77°F) Resolution N/A 0.01% Logger
Logger Operating Range -30° to 70°C (non-condensing) -30° to 70°C (non-condensing) Environmental Rating IP54 IP54 Logging Rate 1 second to 18 hours 1 second to 18 hours Transmission Range Approximately 30.5 m (100 ft) line-of-sight Approximately 30.5 m (100 ft) line-of-sight Memory 128 KB (84,650 measurements, maximum) 178 KB (103,400 total measurements or 51,700 temp & RH paired measurements) Full Memory Download Time Approximately 60 seconds; may take longer the farther the device is from the logger Approximately 60 seconds; may take longer the farther the device is from the logger LCD LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range Battery Type Two AAA 1.5 V alkaline or lithium batteries, user replaceable Two AAA 1.5 V alkaline or lithium batteries, user replaceable Battery Life 1 year, typical with logging interval of 1 minute. Faster logging intervals, remaining connected with the InTemp app, excessive report generation, numerous audible alarms, and paging all impact battery life. 1 year, typical with logging interval of 1 minute. Faster logging intervals, remaining connected with the InTemp app, excessive report generation, numerous audible alarms, and paging all impact battery life. Wireless Data Standard Bluetooth Low Energy (Bluetooth Smart) Bluetooth Low Energy (Bluetooth Smart) Radio Power 1 mW (0 dBm) 1 mW (0 dBm) Dimensions 9.4 x 4.5 x 2.59 cm (3.7 x 1.77 x 1.02 inches) 9.4 x 5.6 x 2.59 cm (3.7 x 2.21 x 1.02 inches) Calibration
InTemp data loggers have an accuracy of +/ 0.5 ºC and come with a NIST certificate of calibration. Advanced certificates of calibration are also available for applications requiring an ISO 17025 compliant certificate.
Certificate is valid for 12 months from the date of manufacture.
Important Information – Certificate of Validation.
The validation certificate supplied with this instrument is from date of manufacture, therefore due to receipt of goods time and shelf time may be partly or fully expired.
It is deemed by OneTemp Pty Ltd that this instrument is not supplied with current certificates of validation. If you need current certificates, please discuss the options we have available before ordering.
-
CX5000 GATEWAY
The CX Gateway links the CX403 & CX450 seamlessly to the InTempConnect cloud-based data platform to provide real-time alert notifications for InTemp loggers automatically.
Just place the Gateway within a 100-foot range of one or more loggers and connect it to your local Wi-Fi or Ethernet. If an excursion occurs, alerts can be sent from InTempConnect via email and text to a user-defined group of administrators.
In addition to flexible alarm notification capabilities, the CX Gateway can automate the process of downloading data from one or more InTemp loggers within range. It can automatically download loggers at fixed intervals – daily, weekly or monthly – or upon arrival of shipments. This saves time and eliminates the need to remove loggers to download them. No more missed downloads of temperature data for your critical temperature-sensitive shipments.
Features
- Notifies you of temperature excursions anywhere, anytime
- Reduces the risk of loss
- Reduces the amount of time spent on data logger download and compliance
- Automates data downloads from InTemp CX400 and 500 Series loggers
In what environment does this communication operate?
- This communication operates in a cold chain environment.
Included Items:
- Mounting Kit
- AC adapter
Required Items:
- CX Gateway Annual Service Plan (SP-CXGTW)
- 12 month plan included in initial price
- $50 US per Gateway/per year ongoing collected by Onset Corporation
- InTempConnect account
- InTemp app
- BLE-enabled device with iOS or Android
- CX series loggers
-
CLOUD SOFTWARE
InTemp Connect Cloudbase software
Automation
Gain visibility into storage areas with automatic excursion alerts and data reports!
Preprogrammed data download
Program the CX5000 Gateway to automatically download data and restart the logger at specified intervals and/or after every excursion.
Always informed, automatically
With the CX5000 Gateway, get automatic email and/or text notifications to alert you to any critical temperature and/or relative humidity alarms, and receive automated reports after the device downloads a logger.
Cloud Reporting
Make critical product-disposition decisions quickly to reduce product loss. Flexible, secure reports provide the data you need, when you need it.
Crucial decisions, made on time
Rely on automated reports after an excursion occurs and make effective, timely product-disposition decisions.
Clear, organized reports
Gather data from individual sites – from a local to global level – and build clear, organized reports for refrigerators, freezers, cold rooms, etc.
Customized reporting that meets your needs
Create custom automated reports for quality assurance (QA) and regulatory auditing, or to determine the efficiency and functionality of temperature-control equipment.
InTemp Cold Storage/Warehouse Temp System
From: $973.00 ex GST
Monitor the temperature in your cold storage/warehouse effortlessly with combining the InTemp CX403 &/or CX450 data loggers and CX5000 gateway for automated alarm notifications and data reports via InTempConnect.
